Inheritance diagram for COperateSSH:

[legend]

Collaboration diagram for COperateSSH:

[legend]

Signals
void	sigReceiveData (const QByteArray &data)

Signals inherited from COperate
void	sigRunning ()
	Start success signal.

void	sigStop ()
	Notify the user to stop.

void	sigFinished ()
	Successful disconnection signal.

void	sigViewerFocusIn (QWidget *pView)
	The view is focus.

void	sigUpdateName (const QString &szName)

void	sigUpdateParameters (COperate *pOperate)
	Update parameters, notify application to save or show parameters.

void	sigError (const int nError, const QString &szError)
	Triggered when an error is generated.

void	sigInformation (const QString &szInfo)
	Show information in main windows.

void	sigShowMessageBox (const QString &title, const QString &message, const QMessageBox::Icon &icon=QMessageBox::Information)
	Trigger the display of a message dialog (QMessageBox) in the main thread from a background thread without blocking the background thread.

void	sigClipBoardChanged ()

Public Member Functions
	COperateSSH (CPlugin *parent)

virtual CBackend *	InstanceBackend () override
	New CBackend.

virtual const QString	Id () override
	Identity.

virtual const QString	Name () override
	Name.

virtual const QString	Description () override
	Description.

virtual SecurityLevel	GetSecurityLevel () override

Public Member Functions inherited from COperateTerminal
	COperateTerminal (CPlugin *parent)

virtual CParameterTerminalBase *	GetParameter ()
	Get parameters.

virtual int	SetParameter (CParameterTerminalBase *pPara)
	Set parameter pointer.

virtual const qint16	Version () const override
	Version.

CStats *	GetStats () override

QWidget *	GetViewer () override
	Get Viewer.

Public Member Functions inherited from COperate
	COperate (CPlugin *plugin)

virtual int	OpenDialogSettings (QWidget *parent=nullptr)
	Open settings dialog.

virtual QMenu *	GetMenu (QWidget *parent=nullptr)
	Get menu.

virtual QString	GetSecurityLevelString ()

virtual QColor	GetSecurityLevelColor ()

virtual int	Start ()=0
	Start.

virtual int	Stop ()=0
	Stop.

virtual const QString	Protocol () const
	Protocol.

virtual const QIcon	Icon () const
	Icon.

virtual const QString	GetTypeName () const
	Get type name.

virtual QString	GetSettingsFile ()

virtual int	SetSettingsFile (const QString &szFile)

Protected Member Functions
virtual int	Initial () override
	Initial parameters and resource.

virtual int	Clean () override
	Clean parameters and resource.

Protected Member Functions inherited from COperateTerminal
virtual int	SetGlobalParameters (CParameterPlugin *pPara) override
	Apply the global parameters of the plug-in.

int	WriteTerminal (const char *buf, int len)

virtual int	Load (QSettings &set) override
	Load parameters.

virtual int	Save (QSettings &set) override
	Save parameters.

virtual void	SetShotcuts (bool bEnable=true)

Protected Member Functions inherited from COperate
Q_INVOKABLE CPlugin *	GetPlugin () const
	Get plugin.

virtual Q_INVOKABLE int	Load (QString szFile=QString())
	Load parameters from file.

virtual Q_INVOKABLE int	Save (QString szFile=QString())
	Save parameters to file.

Private Slots
void	slotReceiveData (const QByteArray &data)

Private Member Functions
virtual QDialog *	OnOpenDialogSettings (QWidget *parent) override
	Open settgins dialog.

Private Attributes
CParameterTerminalSSH	m_Parameters

Additional Inherited Members
Public Types inherited from COperate
enum class	SecurityLevel { No , Secure , NonSecureAuthentication , SecureChannel , Normal = SecureChannel , SecureAuthentication , Risky }

Public Slots inherited from COperateTerminal
virtual int	Start () override

virtual int	Stop () override

Static Public Member Functions inherited from COperateTerminal
static const QString	Details ()

Static Public Member Functions inherited from COperate
static QString	GetSecurityLevelString (SecurityLevel level)

static QColor	GetSecurityLevelColor (SecurityLevel level)

Protected Slots inherited from COperateTerminal
void	slotUpdateParameter (COperate *pOperate)

Protected Slots inherited from COperate
void	slotUpdateName ()

Static Protected Member Functions inherited from COperate
static QObject *	createObject (const QString &className, QObject *parent=NULL)

Protected Attributes inherited from COperateTerminal
QTermWidget *	m_pTerminal

CBackendThread *	m_pThread

QAction *	m_pActionOpenWithSystem

QAction *	m_pActionFind

Protected Attributes inherited from COperate
QMenu	m_Menu

QAction *	m_pActionSettings

Detailed Description

Definition at line 8 of file OperateSSH.h.

Constructor & Destructor Documentation

◆ ~COperateSSH()

COperateSSH::~COperateSSH ( )

virtual

Definition at line 28 of file OperateSSH.cpp.

Member Function Documentation

◆ Clean()

int COperateSSH::Clean ( )

overrideprotectedvirtual

Clean parameters and resource.

See also: CManager::DeleteOperate

Reimplemented from COperateTerminal.

Definition at line 41 of file OperateSSH.cpp.

◆ Description()

const QString COperateSSH::Description ( )

overridevirtual

Description.

Reimplemented from COperateTerminal.

Definition at line 105 of file OperateSSH.cpp.

◆ GetSecurityLevel()

COperateSSH::SecurityLevel COperateSSH::GetSecurityLevel ( )

overridevirtual

Reimplemented from COperate.

Definition at line 56 of file OperateSSH.cpp.

◆ Id()

const QString COperateSSH::Id ( )

overridevirtual

Identity.

Reimplemented from COperateTerminal.

Definition at line 67 of file OperateSSH.cpp.

◆ Initial()

int COperateSSH::Initial ( )

overrideprotectedvirtual

Initial parameters and resource.

See also: CManager::CreateOperate

Reimplemented from COperateTerminal.

Definition at line 33 of file OperateSSH.cpp.

◆ InstanceBackend()

CBackend * COperateSSH::InstanceBackend ( )

overridevirtual

New CBackend.

the ownership is caller. if don't use, the caller must delete it.

Implements COperateTerminal.

Definition at line 51 of file OperateSSH.cpp.

◆ Name()

const QString COperateSSH::Name ( )

overridevirtual

Name.

Reimplemented from COperateTerminal.

Definition at line 84 of file OperateSSH.cpp.

◆ OnOpenDialogSettings()

QDialog * COperateSSH::OnOpenDialogSettings ( QWidget * parent )

overrideprivatevirtual

Open settgins dialog.

Parameters

parent the parent windows of the dialog of return

Returns: QDialog*: then QDialog must be allocated in heap memory, the ownership is caller.

See also: OpenDialogSettings

Implements COperate.

Definition at line 46 of file OperateSSH.cpp.

◆ slotReceiveData

void COperateSSH::slotReceiveData ( const QByteArray & data )

privateslot

Definition at line 61 of file OperateSSH.cpp.

Member Data Documentation

◆ m_Parameters

CParameterTerminalSSH COperateSSH::m_Parameters

private

Definition at line 27 of file OperateSSH.h.

The documentation for this class was generated from the following files:

/home/runner/work/RabbitRemoteControl/RabbitRemoteControl/Plugins/SSH/OperateSSH.h
/home/runner/work/RabbitRemoteControl/RabbitRemoteControl/Plugins/SSH/OperateSSH.cpp
