COperateTemplateServer Class Reference

Inheritance diagram for COperateTemplateServer:

Collaboration diagram for COperateTemplateServer:

Public Member Functions
	COperateTemplateServer (CPlugin *plugin)
virtual CParameterTemplateServer *	GetParameter () const
	Get parameter.
virtual const qint16	Version () const override
Public Member Functions inherited from COperateServer
	COperateServer (CPlugin *plugin)
virtual QWidget *	GetViewer () override
	Get Viewer.
virtual int	Start () override
	Start.
virtual int	Stop () override
	Stop.
Public Member Functions inherited from COperate
	COperate (CPlugin *plugin)
virtual int	OpenDialogSettings (QWidget *parent=nullptr)
	Open settings dialog.
virtual QMenu *	GetMenu (QWidget *parent=nullptr)
	Get menu.
virtual const QString	Id ()
virtual const QString	Name ()
	Name.
virtual const QString	Description ()
	Description.
virtual const QString	Protocol () const
virtual const QIcon	Icon () const
virtual const QString	GetTypeName () const
virtual QString	GetSettingsFile ()
virtual int	SetSettingsFile (const QString &szFile)
virtual CStats *	GetStats ()
	Get statistics.
virtual CSecurityLevel::Levels	GetSecurityLevel () const
	Get Security Level.

Protected Member Functions
virtual int	SetPluginParameters (CParameterPlugin *pPara) override
	Apply the parameters of the plug-in.
virtual Q_INVOKABLE CBackend *	InstanceBackend () override
	New CBackend.
virtual Q_INVOKABLE int	Initial () override
	Initial parameters and resource.
virtual Q_INVOKABLE int	Clean () override
	Clean parameters and resource.
virtual int	Load (QSettings &set) override
	Load parameters.
virtual int	Save (QSettings &set) override
	Save parameters.
Protected Member Functions inherited from COperate
Q_INVOKABLE CPlugin *	GetPlugin () const
	Get plugin.
virtual Q_INVOKABLE int	Load (QString szFile=QString())
	Load parameters from file.
virtual Q_INVOKABLE int	Save (QString szFile=QString())
	Save parameters to file.

Private Member Functions
virtual QDialog *	OnOpenDialogSettings (QWidget *parent) override
	Open settgins dialog.

Private Attributes
CParameterTemplateServer *	m_pPara

Additional Inherited Members
Signals inherited from COperate
void	sigViewerFocusIn (QWidget *pView)
	The view is focus.
void	sigFullScreen (bool bFullScreen)
	Full screen.
void	sigUpdateName (const QString &szName)
void	sigUpdateParameters (COperate *pOperate)
	Update parameters, notify application to save or show parameters.
void	sigError (const int nError, const QString &szError)
	Triggered when an error is generated.
void	sigInformation (const QString &szInfo)
	Show information in main windows.
void	sigShowMessageBox (const QString &title, const QString &message, const QMessageBox::Icon &icon=QMessageBox::Information)
	Trigger the display of a message dialog (QMessageBox) in the main thread from a background thread without blocking the background thread.
void	sigClipBoardChanged ()
void	sigSecurityLevel ()
	Triggered when the security level changes.
void	sigRunning ()
	Start success signal.
void	sigStop ()
	Notify the user to stop.
void	sigFinished ()
	Successful disconnection signal.
Protected Slots inherited from COperate
void	slotUpdateName ()
void	slotSetSecurityLevel (CSecurityLevel::Levels level)
Static Protected Member Functions inherited from COperate
static QObject *	createObject (const QString &className, QObject *parent=NULL)
	Create Object.
Protected Attributes inherited from COperate
QMenu	m_Menu
QAction *	m_pActionSettings

Detailed Description

Definition at line 8 of file OperateTemplateServer.h.

Constructor & Destructor Documentation

~COperateTemplateServer()

COperateTemplateServer::~COperateTemplateServer ( )

virtual

Definition at line 18 of file OperateTemplateServer.cpp.

Member Function Documentation

Clean()

int COperateTemplateServer::Clean ( )

overrideprotectedvirtual

Clean parameters and resource.

See also

CManager::DeleteOperate

Reimplemented from COperateServer.

Definition at line 92 of file OperateTemplateServer.cpp.

GetParameter()

CParameterTemplateServer * COperateTemplateServer::GetParameter ( ) const

virtual

Get parameter.

Definition at line 29 of file OperateTemplateServer.cpp.

Initial()

int COperateTemplateServer::Initial ( )

overrideprotectedvirtual

Initial parameters and resource.

Note

Call before Load()

See also

CManager::CreateOperate Load

Reimplemented from COperateServer.

Definition at line 80 of file OperateTemplateServer.cpp.

InstanceBackend()

CBackend * COperateTemplateServer::InstanceBackend ( )

overrideprotectedvirtual

New CBackend.

the ownership is caller. if don't use, the caller must delete it.

Implements COperateServer.

Definition at line 40 of file OperateTemplateServer.cpp.

Load()

int COperateTemplateServer::Load ( QSettings &  set )

overrideprotectedvirtual

Load parameters.

Implements COperate.

Definition at line 62 of file OperateTemplateServer.cpp.

OnOpenDialogSettings()

QDialog * COperateTemplateServer::OnOpenDialogSettings ( QWidget *  parent )

overrideprivatevirtual

Open settgins dialog.

Parameters

parent

the parent windows of the dialog of return

Returns

QDialog*: then QDialog must be allocated in heap memory, the ownership is caller.

See also

OpenDialogSettings

Implements COperate.

Definition at line 57 of file OperateTemplateServer.cpp.

Save()

int COperateTemplateServer::Save ( QSettings &  set )

overrideprotectedvirtual

Save parameters.

Implements COperate.

Definition at line 72 of file OperateTemplateServer.cpp.

SetPluginParameters()

int COperateTemplateServer::SetPluginParameters ( CParameterPlugin *  pPara )

overrideprotectedvirtual

Apply the parameters of the plug-in.

Note

Call CParameterOperate::SetPluginParameters to set the global parameters for the operation parameters, and connect the signals related to the global parameters.

int COperateDesktop::SetPluginParameters(CParameterPlugin *pPara)
{
    if(GetParameter()) {
        GetParameter()->SetPluginParameters(pPara);

        if(pPara) {
            bool check = connect(pPara, SIGNAL(sigNameStylesChanged()),
                                 this, SLOT(slotUpdateName()));
            Q_ASSERT(check);
        }

        LoadAdaptWindows();
        return 0;
    } else {
        QString szMsg = "There is not parameters! "
                        "please first create parameters, "
                        "then call SetParameter() in the ";
        szMsg += metaObject()->className() + QString("::")
                 + metaObject()->className();
        szMsg += QString("() or ") + metaObject()->className()
                 + QString("::") + "Initial()";
        szMsg += " to set the parameters pointer. "
                 "Default set CParameterClient for the parameters of operate "
                 "(CParameterOperate or its derived classes) "
                 "See CManager::CreateOperate. "
                 "If you are sure the parameter of operate "
                 "does not need CParameterClient. "
                 "Please overload the SetPluginParameters() in the ";
        szMsg += QString(metaObject()->className()) + " . don't set it";
        qCritical(log) << szMsg.toStdString().c_str();
        Q_ASSERT(false);
    }
    return -1;
}

See also

CManager::CreateOperate CParameterPlugin

Implements COperate.

Definition at line 45 of file OperateTemplateServer.cpp.

Version()

const qint16 COperateTemplateServer::Version ( ) const

overridevirtual

Implements COperate.

Definition at line 34 of file OperateTemplateServer.cpp.

Member Data Documentation

m_pPara

CParameterTemplateServer* COperateTemplateServer::m_pPara

private

Definition at line 35 of file OperateTemplateServer.h.

---

The documentation for this class was generated from the following files:

• /home/runner/work/RabbitRemoteControl/RabbitRemoteControl/Plugins/Template/Server/OperateTemplateServer.h
• /home/runner/work/RabbitRemoteControl/RabbitRemoteControl/Plugins/Template/Server/OperateTemplateServer.cpp
