#include <OperatePlayer.h>

Inheritance diagram for COperatePlayer:

[legend]

Collaboration diagram for COperatePlayer:

[legend]

Public Slots
virtual void	slotScreenShot () override

Public Slots inherited from COperateDesktop
virtual int	Start () override

virtual int	Stop () override

virtual void	slotScreenShot ()

Signals
void	sigStart (bool bStart)

void	sigPause (bool bPause)

void	sigChangePosition (qint64 pos)

void	sigScreenShot ()

Signals inherited from COperate
void	sigRunning ()
	Start success signal.

void	sigStop ()
	Notify the user to stop.

void	sigFinished ()
	Successful disconnection signal.

void	sigViewerFocusIn (QWidget *pView)
	The view is focus.

void	sigFullScreen (bool bFullScreen)
	Full screen.

void	sigUpdateName (const QString &szName)

void	sigUpdateParameters (COperate *pOperate)
	Update parameters, notify application to save or show parameters.

void	sigError (const int nError, const QString &szError)
	Triggered when an error is generated.

void	sigInformation (const QString &szInfo)
	Show information in main windows.

void	sigShowMessageBox (const QString &title, const QString &message, const QMessageBox::Icon &icon=QMessageBox::Information)
	Trigger the display of a message dialog (QMessageBox) in the main thread from a background thread without blocking the background thread.

void	sigClipBoardChanged ()

Public Member Functions
	COperatePlayer (CPlugin *plugin)

virtual const qint16	Version () const override
	Version.

Public Member Functions inherited from COperateDesktop
	COperateDesktop (CPlugin *plugin)

virtual CParameterBase *	GetParameter ()
	Get parameter.

virtual int	SetParameter (CParameterBase *p)
	Set parameter pointer.

virtual const QString	Id () override
	Identity.

virtual const QString	Name () override
	Name.

virtual const QString	Description () override
	Description.

virtual QWidget *	GetViewer () override
	Get Viewer.

Public Member Functions inherited from COperate
	COperate (CPlugin *plugin)

virtual int	OpenDialogSettings (QWidget *parent=nullptr)
	Open settings dialog.

virtual QMenu *	GetMenu (QWidget *parent=nullptr)
	Get menu.

virtual CStats *	GetStats ()

virtual SecurityLevel	GetSecurityLevel ()

virtual QString	GetSecurityLevelString ()

virtual QColor	GetSecurityLevelColor ()

virtual int	Start ()=0
	Start.

virtual int	Stop ()=0
	Stop.

virtual const QString	Protocol () const
	Protocol.

virtual const QIcon	Icon () const
	Icon.

virtual const QString	GetTypeName () const
	Get type name.

virtual QString	GetSettingsFile ()

virtual int	SetSettingsFile (const QString &szFile)

Protected Member Functions
virtual CBackend *	InstanceBackend () override
	New CBackend.

virtual int	Initial () override
	Initial parameters and resource.

virtual int	Clean () override
	Clean parameters and resource.

virtual int	InitialMenu () override

Protected Member Functions inherited from COperateDesktop
virtual int	SetGlobalParameters (CParameterPlugin *pPara) override
	Apply the global parameters of the plug-in.

virtual int	Load (QSettings &set) override
	Load parameters.

virtual int	Save (QSettings &set) override
	Save parameters.

virtual QString	ServerName ()
	Current connect server name (remote desktop name, if not present, then IP:PORT).

Protected Member Functions inherited from COperate
Q_INVOKABLE CPlugin *	GetPlugin () const
	Get plugin.

virtual Q_INVOKABLE int	Load (QString szFile=QString())
	Load parameters from file.

virtual Q_INVOKABLE int	Save (QString szFile=QString())
	Save parameters to file.

Private Member Functions
virtual QDialog *	OnOpenDialogSettings (QWidget *parent) override
	Open settgins dialog.

Private Attributes
CParameterPlayer	m_Parameters

QAction *	m_pPause

Additional Inherited Members
Public Types inherited from COperate
enum class	SecurityLevel { No , Secure , NonSecureAuthentication , SecureChannel , Normal = SecureChannel , SecureAuthentication , Risky }

Static Public Member Functions inherited from COperate
static QString	GetSecurityLevelString (SecurityLevel level)

static QColor	GetSecurityLevelColor (SecurityLevel level)

Protected Slots inherited from COperate
void	slotUpdateName ()

Static Protected Member Functions inherited from COperate
static QObject *	createObject (const QString &className, QObject *parent=NULL)

Protected Attributes inherited from COperateDesktop
QAction *	m_pMenuZoom

QAction *	m_pZoomToWindow

QAction *	m_pZoomAspectRatio

QAction *	m_pZoomOriginal

QAction *	m_pZoomIn

QAction *	m_pZoomOut

QSpinBox *	m_psbZoomFactor

QAction *	m_pScreenShot

Protected Attributes inherited from COperate
QMenu	m_Menu

QAction *	m_pActionSettings

Detailed Description

See also

Definition at line 23 of file OperatePlayer.h.

Constructor & Destructor Documentation

◆ ~COperatePlayer()

COperatePlayer::~COperatePlayer ( )

virtual

Definition at line 17 of file OperatePlayer.cpp.

Member Function Documentation

◆ Clean()

int COperatePlayer::Clean ( )

overrideprotectedvirtual

Clean parameters and resource.

See also: CManager::DeleteOperate

Reimplemented from COperateDesktop.

Definition at line 176 of file OperatePlayer.cpp.

◆ Initial()

int COperatePlayer::Initial ( )

overrideprotectedvirtual

Initial parameters and resource.

See also: CManager::CreateOperate

Reimplemented from COperateDesktop.

Definition at line 27 of file OperatePlayer.cpp.

◆ InitialMenu()

int COperatePlayer::InitialMenu ( )

overrideprotectedvirtual

Reimplemented from COperateDesktop.

Definition at line 46 of file OperatePlayer.cpp.

◆ InstanceBackend()

CBackend * COperatePlayer::InstanceBackend ( )

overrideprotectedvirtual

New CBackend.

the ownership is caller. if don't use, the caller must delete it.

Implements COperateDesktop.

Definition at line 190 of file OperatePlayer.cpp.

◆ OnOpenDialogSettings()

QDialog * COperatePlayer::OnOpenDialogSettings ( QWidget * parent )

overrideprivatevirtual

Open settgins dialog.

Parameters

parent the parent windows of the dialog of return

Returns: QDialog*: then QDialog must be allocated in heap memory, the ownership is caller.

See also: OpenDialogSettings

Implements COperate.

Definition at line 184 of file OperatePlayer.cpp.

◆ slotScreenShot

void COperatePlayer::slotScreenShot ( )

overridevirtualslot

Definition at line 196 of file OperatePlayer.cpp.

◆ Version()

const qint16 COperatePlayer::Version ( ) const

overridevirtual

Version.

Reimplemented from COperateDesktop.

Definition at line 22 of file OperatePlayer.cpp.

Member Data Documentation

◆ m_Parameters

CParameterPlayer COperatePlayer::m_Parameters

private

Definition at line 56 of file OperatePlayer.h.

◆ m_pPause

QAction* COperatePlayer::m_pPause

private

Definition at line 72 of file OperatePlayer.h.

The documentation for this class was generated from the following files:

/home/runner/work/RabbitRemoteControl/RabbitRemoteControl/Plugins/Player/OperatePlayer.h
/home/runner/work/RabbitRemoteControl/RabbitRemoteControl/Plugins/Player/OperatePlayer.cpp
